linearity, it is unnecessary for the end-user to perform this tedious
C AD654
and time consuming test on a routine basis. Sufficient FS calibration trim range must be provided to accom-
RCOMP
modate the worst-case sum of all major scaling errors. This
R1 R2
includes the AD654’s 10% full-scale error, the tolerance of the
VIN
fixed scaling resistor, and the tolerance of the timing capacitor. Therefore, with a resistor tolerance of 1% and a capacitor tolerance Figure 3b. Bias Current Compensation—Negative Inputs of 5%, the fixed part of the scaling resistor should be a maximum If the AD654’s 1 mV offset voltage must be trimmed, the trim of 84% of nominal, with the variable portion selected to allow must be performed external to the device. Figure 3c shows an 116% of the nominal. optional connection for positive inputs in which ROFF1 and If the input is in the form of a negative current source, the scaling ROFF2 add a variable resistance in series with RT. A variable resistor is no longer required, eliminating the capability of trim- source of ± 0.6 V applied to ROFF1 then adjusts the offset ± 1 mV. ming FS frequency in this fashion. Since it is usually not practical Similarly, a ± 0.6 V variable source is applied to ROFF in Fig- to smoothly vary the capacitance for trimming purposes, an ure 3d to trim offset for negative inputs. The ± 0.6 V bipolar alternative scheme such as the one shown in Figure 4 is needed. source could simply be an AD589 reference connected as shown Designed for a FS of 1 mA, this circuit divides the input into two in Figure 3e.
R2 100
V
AD654 AD654 10k
V
R4 VIN 392
V
R3 I 1k S
V
ROFF2 20
V
5k
V
8.25k
V
R1 100
V
ROFF1 I 1mA R 10k
V
FS ROFF I * S 100k
V
f =
6
0.6V (20V) CT –V
6
0.6V
Figure 3c. Offset Trim Positive Input (10 V FS)
*OPTIONAL OFFSET TRIM
6
0.6V
Figure 4. Current Source FS Trim
ROFF
and flowing into Pin 3; it constitutes the signal current I
5.6M
V T to be
AD654
converted. The second path, through another 100 Ω resistor R2,
10k
V carries the same nominal current. Two equal valued resistors offer the best overall stability, and should be either 1% discrete
8.25k
V
5k
V film units, or a pair from a common array.
VIN
Since the 1 mA FS input current is divided into two 500 µA legs (one to ground and one to Pin 3), the total input signal current Figure 3d. Offset Trim Negative Input (–10 V FS) (IS) is divided by a factor of two in this network. To achieve the same conversion scale factor, C
R1
T must be reduced by a factor of
10k
V two. This results in a transfer unique to this hookup:
+5V R3
f = IS
+ 10k
V (20 V ) C
R5
6 T
0.6V AD589 100k
V
–
For calibration purposes, resistors R3 and R4 are added to the
R4 10k R2
V network, allowing a ± 15% trim of scale factor with the values
10k
V
–5V
shown. By varying R4’s value the trim range can be modified to accommodate wider tolerance components or perhaps the cali- Figure 3e. Offset Trim Bias Network bration tolerance on a current output transducer such as the AD592 temperature sensor. Although the values of R1–R4 shown
