LTC6102 LTC6102-1/LTC6102HV
absoluTe MaxiMuM raTings (Note 1)
Total Supply Voltage (V+ to V–): Output Current ...(–1mA, +10mA) LTC6102/LTC6102-1 ...70V Output Short Circuit Duration... Indefinite LTC6102HV ...105V Operating Temperature Range: (Note 2) Input Voltage Range LTC6102C/LTC6102C-1/LTC6102HVC .. –40°C to 85°C –INF, –INS .. (V+ – 4V to V+ + 0.3V) LTC6102I/LTC6102I-1/LTC6102HVI .. –40°C to 85°C +IN .. (V+ – 20V to V+ + 1V) LTC6102H/LTC6102H-1 EN .. (V– – 0.3V to V– + 9V) LTC6102HVH.. –40°C to 125°C Differential (–INS – +IN), 1 Second ..60V Specified Temperature Range: (Note 2) Output Voltage Range LTC6102C/LTC6102C-1/LTC6102HVC .. 0°C to 70°C LTC6102/LTC6102HV ... (V– – 0.3V to V– + 9V) LTC6102I/LTC6102I-1/LTC6102HVI .. –40°C to 85°C LTC6102-1 ... (V– – 0.3V to V– + 15V) LTC6102H/LTC6102H-1 Input Current LTC6102HVH.. –40°C to 125°C –INF, –INS ..±10mA Storage Temperature Range ... –65°C to 150°C +IN ...–10mA EN ..±10mA
pin conFiguraTion
TOP VIEW –INS 1 8 +IN TOP VIEW –INF 2 7 V+ –INS 1 8 +IN 9 –INF 2 7 V+ V–/EN* 3 6 VREG V–/EN* 3 6 VREG OUT 4 5 V– OUT 4 5 V– MS8 PACKAGE 8-LEAD PLASTIC MSOP DD PACKAGE 8-LEAD (3mm × 3mm) PLASTIC DFN T JMAX = 150°C, θJA = 200°C/W T *V– FOR THE LTC6102/LTC6102HV, EN FOR THE LTC6102-1 JMAX = 150°C, θJA = 43°C/W EXPOSED PAD (PIN 9) IS V–, MUST BE SOLDERED TO PCB *V– FOR THE LTC6102/LTC6102HV, EN FOR THE LTC6102-1
orDer inForMaTion LEAD FREE FINISH TAPE AND REEL PART MARKING* PACKAGE DESCRIPTION SPECIFIED TEMPERATURE RANGE
LTC6102CDD#PBF LTC6102CDD#TRPBF LCKH 8-Lead (3mm × 3mm) Plastic DFN 0°C to 70°C LTC6102IDD#PBF LTC6102IDD#TRPBF LCKH 8-Lead (3mm × 3mm) Plastic DFN –40°C to 85°C LTC6102HDD#PBF LTC6102HDD#TRPBF LCKH 8-Lead (3mm × 3mm) Plastic DFN –40°C to 125°C LTC6102CDD-1#PBF LTC6102CDD-1#TRPBF LDYB 8-Lead (3mm × 3mm) Plastic DFN 0°C to 70°C LTC6102IDD-1#PBF LTC6102IDD-1#TRPBF LDYB 8-Lead (3mm × 3mm) Plastic DFN –40°C to 85°C LTC6102HDD-1#PBF LTC6102HDD-1#TRPBF LDYB 8-Lead (3mm × 3mm) Plastic DFN –40°C to 125°C LTC6102HVCDD#PBF LTC6102HVCDD#TRPBF LCVC 8-Lead (3mm × 3mm) Plastic DFN 0°C to 70°C LTC6102HVIDD#PBF LTC6102HVIDD#TRPBF LCVC 8-Lead (3mm × 3mm) Plastic DFN –40°C to 85°C LTC6102HVHDD#PBF LTC6102HVHDD#TRPBF LCVC 8-Lead (3mm × 3mm) Plastic DFN –40°C to 125°C LTC6102CMS8#PBF LTC6102CMS8#TRPBF LTCKJ 8-Lead Plastic MSOP 0°C to 70°C LTC6102IMS8#PBF LTC6102IMS8#TRPBF LTCKJ 8-Lead Plastic MSOP –40°C to 85°C 6102fe 2 For more information www.linear.com/LTC6102
