HMC609
v03.0210
GaAs PHEMT MMIC LOW NOISE AMPLIFIER, 2 - 4 GHz
1
Absolute Maximum Ratings Typical Supply Current vs. Vdd
Drain Bias Voltage (Vdd) 7 Vdc Vdd (V) Idd (mA) RF Input Power (RFIN)(Vdd = +5 Vdc) +15 dBm +5.5 160 IP Channel Temperature 175 °C +6.0 170 H Continuous Pdiss (T = 85 °C) +6.5 180 1.64 W (derate 18 mW/°C above 85 °C) Note: Amplifi er will operate over full voltage range shown above Thermal Resistance 55 °C/W (channel to ground pad) E - C Storage Temperature -65 to +150 °C IS ELECTROSTATIC SENSITIVE DEVICE Operating Temperature -55 to +85 °C OBSERVE HANDLING PRECAUTIONS W NO O
