HMC789ST89E
v02.0314
InGaP HBT GAIN BLOCK MMIC AMPLIFIER, 0.7 -2.8 GHz Typical Applications Features
The HMC789ST89E is ideal for: High Output IP3: +42 dBm T • Cel ular/4G High Output P1dB: +25 dBm M • Fixed Wireless & WLAN High Gain: 18 dB • CATV, Cable Modem & DBS Single Supply: +5V K - S • Microwave Radio & Test Equipment 45% PAE @ +25 dBm Pout C • IF & RF Applications Industry Standard SOT89 Package LO
Functional Diagram General Description
IN B The HMC789ST89E is a high linearity GaAs InGaP A HBT gain block MMIC operating from 0.7 to 2.8 GHz and packaged in an industry standard SOT89 package. Utilizing a minimum number of external components and a single +5V supply, the amplifier output IP3 can R & G be optimized to +45 dBm. The high output IP3 and E high gain make the HMC789ST89E ideal for use in IV PA driver & pre-driver applications in Cel ular/4G and R Fixed Wireless. S - D R IE LIF P M A
Electrical Specifications, T = +25°C, Vs= +5V [1] A
Parameter Min. Typ. Max. Min. Typ. Max. Min. Typ. Max. Units Frequency Range 810 - 960 1710 - 1990 2420 - 2700 MHz Gain 17 18 12 13.5 10 11 dB Gain Variation Over Temperature 0.01 0.01 0.01 dB / °C Input Return Loss 12 12 10 dB Output Return Loss 20 15 10 dB Output Power for 1dB Compression (P1dB) 21 23.5 23 25 22 24 dBm Saturated Output Power (Psat) 25.5 27 26 dBm Output Third Order Intercept (IP3) [2] 42 42 42 dBm Noise Figure 3.8 3.8 3.8 dB Supply Current (Icq) 125 150 125 150 125 150 mA [1] Specifications and data reflect HMC789ST89E measured using the respective application circuits for each designated frequency band found herein. Contact the HMC Applications Group for assistance in optimizing performance for your application. [2] Two-tone output power of +10 dBm per tone, 1 MHz spacing. I F nf o or r p mati r o in cfe ur , d nish e e l d iv b e y r A y a nalo n g d t Devi o p ces i la s c bele o ieve rd d t e o rbs e : H acc iutrtatite e M and ic reli rao bl w e. a H v o e C wever o , nrp o For price, delivery, and to place orders: Analog Devices, Inc., responsibility is assumed by Analog Devices for its use, nor for any infringements of patents or other oration, 2 Elizabeth Drive, Chelmsford, MA 01824 One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106 Phone: 978-250-3343 Fax: 978-250-3373 O rights of third parties that may result from its use. Specifications subject to change without notice. No rd Phoe n r O e: 7 n- 81-li 3 n 2 e a 9-4 t w 70 ww 0 • O . rdh e itt r o it nle i . n co e a m
