Datasheet AD834 (Analog Devices) - 4

link to page 12 link to page 11 link to page 4
AD834 Data Sheet Parameters Conditions Min Typ Max Unit
POWER SUPPLIES Operating Range ±4 ±9 V Quiescent Current6 TMIN to TMAX +VS 11
14
mA –VS 28
35
mA 1 Error is defined as the maximum deviation from the ideal output, and expressed as a percentage of the full-scale output. See Figure 16. 2 Both supplies taken simultaneously; sinusoidal input at f ≤10 kHz. 3 Linearity is defined as residual error after compensating for input offset voltage, output offset current, and scaling current errors. 4 Bandwidth is guaranteed when configured in squarer mode. See Figure 12. 5 Sine input; relative to full-scale output; zero input port nulled; represents feedthrough of the fundamental. 6 Negative supply current is equal to the sum of positive supply current, the signal currents into each output, W1 and W2, and the input bias currents. Rev. F | Page 4 of 20 Document Outline Features Applications Functional Block Diagram General Description Product Highlights Revision History Specifications Absolute Maximum Ratings Thermal Characteristics Chip Dimensions and Bonding Diagram ESD Caution Pin Configuration and Function Descriptions Typical Performance Characteristics Test Circuits Explanation of Typical Performance Characteristics and Test Circuits Theory of Operation Transfer Function Biasing the Output Transformer Coupling Wideband Multiplier Connections Power Measurement (Mean-Square and RMS) Frequency Doubler Wideband Three-Signal Multiplier/Divider Outline Dimensions Ordering Guide
