LT8491
ELECTRICAL CHARACTERISTICS The
l
denotes the specifications which apply over the full operating temperature range, otherwise specifications are at TA = 25°C. VIN = 12V, VDD = AVDD = 3.3V, SHDN = 3V unless otherwise noted. (Note 3) PARAMETER CONDITIONS MIN TYP MAX UNITS Switching Regulator Oscillator (OSC1)
Switch Frequency Range Syncing or Free Running 100 400 kHz Switching Frequency, fOSC RT = 365kΩ l 102 120 142 kHz RT = 215kΩ l 170 202 235 kHz RT = 124kΩ l 310 350 400 kHz SYNC High Level for Synchronization l 1.3 V SYNC Low Level for Synchronization l 0.5 V SYNC Clock Pulse Duty Cycle VSYNC = 0V to 2V 20 80 % Recommended Min SYNC Ratio, fSYNC/fOSC ¾ f/f CLKOUT Output Voltage HIGH 1mA Out of CLKOUT Pin 2.3 2.45 2.55 V CLKOUT Output Voltage LOW 1mA into CKLKOUT Pin 25 100 mV CLKOUT Duty Cycle TJ = –40°C 22.7 % TJ = 25°C 44.1 % TJ = 125°C 77 %
