Datasheet SLND (Songle Relay)

SLND Series 30A 17MAX Features X A M 0 X 24.7M A AX 2 ·30A switching capability 21.8M ·1 Form A and 1 Form B type avaliable X · A Mouting Form : metal bracket M .5 8 3 Ordering Information Contact Rating SLND-12- R-A Contact arrangment A /B Voltage drop ≤200mV Contact material Silver alloy:AgCdO、AgSnO2、AgNi A/B Contact rating 30A 14VDC Contact arrangment Max switching voltage 30 VDC R:resistor/D:diode Without:without parallel components c Parallel oil components Max switching current 35A （Resistive 14VDC） 12VDC/ 24VDC Mini contact load 1A 6VDC Coil Voltage Electrical endurance 5 (frequency: 900 ops/h) 1x10 ops Part number endurance Mechanical 7 (frequency: 18000 ops/h) 1x10 ops Characteristics Coil Data （ 20 at ℃） Insulation system Class B / Class F Power Voltage Current Resistance dissipation Pick-up Drop-out Max Insulation resistance 100MΩ(500VDC) W VDC ± Ω 10% Ω voltage voltage allowable Dielectric Between contacts 550VAC 1minute 1. 5 12 96 Strength and coil Between open 1. 7 12 96 680 550VAC 1minute contacts 70%Max 10%Min 130% 1. 5 24 384 Operate time(Under nominal voltage) ≤10ms 1. 7 24 384 2700 Release time(Under nominal voltage) ≤10ms Humidity 85% RH（20℃） Ambient Temperature -40℃~+125℃ Functional 98m/s
²
Shock resistance Destructive 980m/s
²
Vibration resistance 5Hz
~
22.3Hz 10mm ( Double amplitude) Approx 31.5g Weight Construction Sealed Remark:1)All above data is initial value This product specification only for your reference, we will not notify you if we do any improvement.We reserve all the right for the final explanation Web：www.songle.com www.songlerelay.com Email:sale@songle.com Web：www.songle.com www.songlerelay.com Add.：CW7, Zone A, Far East Industrial Park, Yuyao City, Zhejiang, China i Z p Code：315400 Add.：CW7, Zone A, Far East Industrial Park, Yuyao City, Zhejiang, China Zip Code：315400 Tel.： +86 574 62717777 62762658 62721968 a F x：+86 574 62721978 Document Outline 页 1 页 2
