LT1395/LT1396/LT1397
PIN FUNCTIONS LT1395CS5 LT1397CS, LT1397CDE, LT1397HDE OUT (Pin 1):
Output.
OUT A (Pin 1):
A Channel Output.
V – (Pin 2):
Negative Supply Voltage, Usually –5V.
– IN A (Pin 2):
Inverting Input of A Channel Amplifi er.
+IN (Pin 3):
Noninverting Input.
+ IN A (Pin 3):
Noninverting Input of A Channel Amplifi er.
– IN (Pin 4):
Inverting Input.
V + (Pin 4):
Positive Supply Voltage, Usually 5V.
V+ (Pin 5):
Positive Supply Voltage, Usually 5V.
+ IN B (Pin 5):
Noninverting Input of B Channel Amplifi er.
– IN B (Pin 6):
Inverting Input of B Channel Amplifi er.
LT1395CS6 OUT B (Pin 7):
B Channel Output.
OUT (Pin 1):
Output.
OUT C (Pin 8):
C Channel Output.
V – (Pin 2):
Negative Supply Voltage, Usually –5V.
– IN C (Pin 9):
Inverting Input of C Channel Amplifi er.
+ IN (Pin 3):
Noninverting Input.
+IN C (Pin 10):
Noninverting Input of C Channel Amplifi er.
– IN (Pin 4):
Inverting Input.
V – (Pin 11):
Negative Supply Voltage, Usually –5V.
EN (Pin 5):
Enable Pin. Logic low to enable.
+IN D (Pin 12):
Noninverting Input of D Channel Amplifi er.
V+ (Pin 6):
Positive Supply Voltage, Usually 5V.
– IN D (Pin 13):
Inverting Input of D Channel Amplifi er.
LT1395CS8 OUT D (Pin 14):
D Channel Output.
NC (Pin 1):
No Connection.
LT1397CGN – IN (Pin 2):
Inverting Input.
OUT A (Pin 1):
A Channel Output.
+ IN (Pin 3):
Noninverting Input.
– IN A (Pin 2):
Inverting Input of A Channel Amplifi er.
V – (Pin 4):
Negative Supply Voltage, Usually –5V.
+ IN A (Pin 3):
Noninverting Input of A Channel Amplifi er.
NC (Pin 5):
No Connection.
V+ (Pin 4):
Positive Supply Voltage, Usually 5V.
OUT (Pin 6):
Output.
+ IN B (Pin 5):
Noninverting Input of B Channel Amplifi er.
V+ (Pin 7):
Positive Supply Voltage, Usually 5V.
– IN B (Pin 6):
Inverting Input of B Channel Amplifi er.
NC (Pin 8):
No Connection.
OUT B (Pin 7):
B Channel Output.
LT1396CMS8, LT1396CS8, LT1396CDD NC (Pin 8):
No Connection.
OUT A (Pin 1):
A Channel Output.
NC (Pin 9):
No Connection.
– IN A (Pin 2):
Inverting Input of A Channel Amplifi er.
OUT C (Pin 10):
C Channel Output.
+ IN A (Pin 3):
Noninverting Input of A Channel Amplifi er.
– IN C (Pin 11):
Inverting Input of C Channel Amplifi er.
V – (Pin 4):
Negative Supply Voltage, Usually –5V.
+IN C (Pin 12):
Noninverting Input of C Channel Amplifi er.
+ IN B (Pin 5):
Noninverting Input of B Channel Amplifi er.
V– (Pin 13):
Negative Supply Voltage, Usually –5V.
– IN B (Pin 6):
Inverting Input of B Channel Amplifi er.
+IN D (Pin 14):
Noninverting Input of D Channel Amplifi er.
OUT B (Pin 7):
B Channel Output.
– IN D (Pin 15):
Inverting Input of D Channel Amplifi er.
V + (Pin 8):
Positive Supply Voltage, Usually 5V.
OUT D (Pin 16):
D Channel Output. 139567fd 9
