MCP6N11 1.0 ELECTRICAL † Notice:
Stresses above those listed under “Absolute
CHARACTERISTICS
Maximum Ratings” may cause permanent damage to the device. This is a stress rating only and functional operation of the device at those or any other
1.1 Absolute Maximum Ratings †
conditions above those indicated in the operational V listings of this specification is not implied. Exposure to DD – VSS ...6.5V maximum rating conditions for extended periods may Current at Input Pins
††
...±2 mA affect device reliability. Analog Inputs (VIP and VIM)
††
... VSS – 1.0V to VDD + 1.0V All Other Inputs and Outputs ... V
††
See
Section 4.2.1.2 “Input Voltage Limits”
and SS – 0.3V to VDD + 0.3V Difference Input Voltage... |V
Section 4.2.1.3 “Input Current Limits”
. DD – VSS| Output Short Circuit Current .. Continuous Current at Output and Supply Pins ..±30 mA Storage Temperature ...-65°C to +150°C Max. Junction Temperature .. +150°C ESD protection on al pins (HBM, CDM, MM) .≥ 2 kV, 1.5 kV, 300V
1.2 Specifications TABLE 1-1: DC ELECTRICAL SPECIFICATIONS Electrical Characteristics:
Unless otherwise indicated, TA = +25°C, VDD = 1.8V to 5.5V, VSS = GND, EN/CAL = VDD, VCM = VDD/2, VDM = 0V, VREF = VDD/2, VL = VDD/2, RL = 10 kΩ to VL and GDM = GMIN; see Figure 1-6 and Figure 1-7.
Parameters Sym Min Typ Max Units GMIN Conditions Input Offset
Input Offset Voltage, VOS -3.0 — +3.0 mV 1
(Note 2 )
Calibrated -2.0 — +2.0 mV 2 -0.85 — +0.85 mV 5 -0.50 — +0.50 mV 10 -0.35 — +0.35 mV 100 Input Offset Voltage VOSTRM — 0.36 — mV 1 Trim Step — 0.21 — mV 2 — 0.077 — mV 5 — 0.045 — mV 10 — 0.014 — mV 100 Input Offset Voltage ΔVOS/ΔTA — ±90/GMIN — µV/°C 1 to 10 TA= -40°C to +125°C Drift
(Note 3 )
— ±2.7 — µV/°C 100 Power Supply PSRR 62 82 — dB 1 Rejection Ratio 68 88 — dB 2 75 96 — dB 5 81 102 — dB 10 86 112 — dB 100
Note 1:
VCM = (VIP + VIM) / 2, VDM = (VIP – VIM) and GDM = 1 + RF/RG.
2:
The VOS spec limits include 1/f noise effects.
3:
This is the input offset drift without VOS re-calibration; toggle EN/CAL to minimize this effect.
4:
These specs apply to both the VIP, VIM input pair (use VCM) and to the VREF, VFG input pair (VREF takes VCM’s place).
5:
This spec applies to the VIP, VIM, VREF and VFG pins individually.
6:
Figure 2-11 and Figure 2-19 show the VIVR and VDMR variation over temperature.
7:
See
Section 1.5 “Explanation of DC Error Specs”.
