Data Sheet AD7739 Parameter Min Typ Max Unit Test Conditions/Comments
POWER REQUIREMENTS AVDD to AGND Voltage 4.75 5.25 V DVDD to DGND Voltage 4.75 5.25 V 2.70 3.60 V AVDD Current (Normal Mode) 13.6 16 mA AVDD Current (Reduced Power Mode) 9.2 11 mA MCLK = 4 MHz AVDD Current (Internal Buffer Off ) 8.5 mA DVDD Current (Normal Mode)13 2.7 3 mA DVDD = 5 V DVDD Current (Normal Mode)13 1.0 1.5 mA DVDD = 3 V Power Dissipation (Normal Mode)13 85 100 mW Power Dissipation (Reduced Power 60 70 mW DVDD = 5 V, MCLK = 4 MHz Mode)13 Power Dissipation (Reduced Power 50 mW DVDD = 3 V, MCLK = 4 MHz Mode)13 AVDD + DVDD Current (Standby 80 μA Mode)14 Power Dissipation (Standby Mode)14 500 μW 1 Specification is not production tested, but is supported by characterization data at initial product release. 2 See Typical Performance Characteristics. 3 Specifications before calibration. Channel system calibration reduces these errors to the order of the noise. 4 Applies after the zero-scale and full-scale calibration. The negative full-scale error represents the remaining error after removing the offset and gain error. 5 Specifications before calibration. ADC zero-scale self-calibration or channel zero-scale system calibration reduce this error to the order of the noise. 6 For specified performance. The output data span corresponds to the specified nominal input voltage range. The ADC is functional outside the nominal input voltage range, but the performance might degrade. Outside the nominal input voltage range, the OVR bit in the channel status register is set and the channel data register value depends on the clamp bit in the mode register. See the register and circuit descriptions for details. 7 For specified performance. If the analog input absolute voltage (referred to AGND) changes more than 0.5 V during one conversion time, the result can be affected by distortion in the input buffer. This limit does not apply to analog input absolute voltages below 3 V. 8 If chopping is enabled or when switching between channels, a dynamic current charges the capacitance of the multiplexer. See the circuit description for details. 9 For specified performance. Part is functional with lower VREF. 10 Dynamic current charging the sigma-delta (Σ-Δ) modulator input switching capacitor. 11 Outside the specified calibration range, calibration is possible but the performance may degrade. 12 These logic output levels apply to the MCLK OUT output when it is loaded with a single CMOS load. 13 With external MCLK, MCLKOUT disabled (CLKDIS bit set in the mode register). 14 External MCLKIN = 0 V or DVDD, digital inputs = 0 V or DVDD, P0 and P1 = 0 V or AVDD.
TIMING SPECIFICATIONS
AVDD = 5 V ± 5%, DVDD = 2.7 V to 3.6 V or 5 V ± 5%, Input Logic 0 = 0 V, Logic 1 = DVDD, unless otherwise noted.1
Table 2. Parameter Min Typ Max Unit Test Conditions/Comments
MASTER CLOCK RANGE 1 6.144 MHz 1 4 MHz Reduced power mode t1 50 ns SYNC pulse width t2 500 ns RESET pulse width READ OPERATION t4 0 ns CS falling edge to SCLK falling edge setup time t 2 5 SCLK falling edge to data valid delay 0 60 ns DVDD of 4.75 V to 5.25 V 0 80 ns DVDD of 2.7 V to 3.3 V t 2, 3 5A CS falling edge to data valid delay 0 60 ns DVDD of 4.75 V to 5.25 V 0 80 ns DVDD of 2.7 V to 3.3 V t6 50 ns SCLK high pulse width t7 50 ns SCLK low pulse width t8 0 ns CS rising edge after SCLK rising edge hold time t 4 9 10 80 ns Bus relinquish time after SCLK rising edge Rev. A | Page 5 of 32 Document Outline Features Applications Functional Block Diagram General Description Table of Contents Revision History Specifications Timing Specifications Timing Diagrams Absolute Maximum Ratings ESD Caution Pin Configuration and Function Descriptions Typical Performance Characteristics Output Noise and Resolution Specification Chopping Enabled Chopping Disabled Register Descriptions Register Access Communications Register 8 Bits, Write-Only Register, Address 0x00 I/O Port Register 8 Bits, Read/Write Register, Address 0x01, Default Value 0x30 + Digital Input Value × 0x40 Revision Register 8 Bits, Read-Only Register, Address 0x02, Default Value 0x09 + Chip Revision × 0x10 Test Register 24 Bits, Read/Write Register, Address 0x03 ADC Status Register 8 Bits, Read-Only Register, Address 0x04, Default Value 0x00 Checksum Register 16 Bits, Read/Write Register, Address 0x05 ADC Zero-Scale Calibration Register 24 Bits, Read/Write Register, Address 0x06, Default Value 0x80 0000 ADC Full-Scale Calibration Register 24 Bits, Read/Write Register, Address 0x07, Default Value 0x80 0000 Channel Data Registers 16-Bit/24-Bit, Read-Only Registers, Address 0x08 to Address 0x0F, Default Width 16 Bits, Default Value 0x8000 Channel Zero-Scale Calibration Registers 24 Bits, Read/Write Registers, Address 0x10 to Address 0x17, Default Value 0x80 0000 Channel Full-Scale Calibration Registers 24 Bits, Read/Write Registers, Address 0x18 to Address 0x1F, Default Value 0x20 0000 Channel Status Registers 8 Bits, Read-Only Registers, Address 0x20 to Address 0x27, Default Value 0x20 × Channel Number Channel Setup Registers 8 Bits, Read/Write Registers, Address 0x28 to Address 0x2F, Default Value 0x00 Channel Conversion Time Registers 8 Bits, Read/Write Registers, Address 0x30 to Address 0x37, Default Value 0x91 Mode Register 8 Bits, Read/Write Register, Address 0x38 to Address 0x3F, Default Value 0x00 Digital Interface Description Hardware Reset Access the AD7739 Registers Single Conversion and Reading Data Dump Mode Continuous Conversion Mode Continuous Read (Continuous Conversion) Mode Circuit Description Analog Inputs Sigma-Delta ADC Chopping Multiplexer, Conversion, and Data Output Timing Frequency Response Extended Voltage Range of the Analog Input Voltage Reference Inputs Reference Detect I/O Port Calibration ADC Zero-Scale Self-Calibration ADC Full-Scale Self-Calibration Per Channel System Calibration Outline Dimensions Ordering Guide
