Datasheet SKM 100GB128D - Semikron IGBT MODULE, DUAL, SPT, 1200 V, 145 A — Ficha de datos

Descripción detallada

Manufacturer: Semikron

Description: IGBT MODULE, DUAL, SPT, 1200 V, 145 A

Specifications:

• Av Current Ic: 145 A
• Collector Emitter Voltage V(br)ceo: 1.2 kV
• Collector Emitter Voltage Vces: 2.35 V
• Current Ic Continuous a Max: 145 A
• Current Ic Continuous b Max: 105 A
• Current Temperature: 25°C
• External Depth: 30.5 mm
• External Length / Height: 26 mm
• External Width: 94 mm
• Fall Time tf: 65 ns
• Fixing Centres: 80 mm
• Mounting Type: Screw
• Number of Transistors: 2
• Package / Case: SEMITRANS 2
• Rise Time: 38 ns
• Transistor Case Style: SEMITRANS 2
• Transistor Polarity: N Channel
• Transistor Type:
• Voltage Vces: 1.2 kV

RoHS: Yes
