Datasheet FSBB20CH60C - Fairchild 6-PACK IGBT MODULE 20 A 600 V 3 PH — Ficha de datos

Descripción detallada

Manufacturer: Fairchild

Description: 6-PACK IGBT MODULE 20 A 600 V 3 PH

Download Data Sheet

Docket:
FSBB20CH60C Smart Power Module
February 2008
FSBB20CH60C
Smart Power Module
Features

Specifications:

• Transistor Type: IGBT
• DC Collector Current: 20 A
• Max Voltage Vce Sat: 2 V
• Max Power Dissipation: 62 W
• Collector-to-Emitter Breakdown Voltage: 600 V
• Operating Temperature Range: -40°C to +150°C
• Transistor Case Style: SPM27-CC
• Number of Pins: 27
• Case Style: SPM27-CC
• Max Current Ic Continuous a: 20 A
• Power Dissipation: 62 W
• Termination Type: Through Hole
• Transistor Polarity: N Channel
• Voltage Vces: 600 V
