Datasheet Wago 721-2212/037-000 — Ficha de datos
Conector hembra de 2 conductores; 100% protegido contra desajustes; Palanca de cierre; 2,5 mm²; Espaciado de pasador de 7,5 mm; 12 polos
Precios
Descripción detallada
Paramétricos
| Actuation type | Operating tool |
| Clamping spring material | Chrome nickel spring steel (CrNi) |
| Color | light gray |
| Connection technology | Push-in CAGE CLAMP® |
| Connector connection type | for conductors |
| Contact material | Copper alloy |
| Contact plating | tin-plated |
| Contact type (pluggable connector) | Female connector/socket |
| Страна происхождения | PL |
| Depth | 29.8 mm / 1.173 inch |
| Fine-stranded conductor | 0.2 … 2.5 mm² / 24 … 12 AWG |
| Fine-stranded conductor with ferrule with plastic collar | 0.25 … 1.5 mm² |
| Fine-stranded conductor with ferrule without plastic collar | 0.25 … 2.5 mm² |
| Fire load | 0.683 MJ |
| Flammability class per UL94 | V0 |
| Global Trade Item Number (GTIN) | 4044918567848 |
| Height | 20.8 mm / 0.819 inch |
| Insulating material | Polyamide 66 (PA 66) |
| Legend (ratings) | (III / 2) ≙ Overvoltage category III / Pollution degree 2 |
| Limit temperature range | -60 … +85 °C |
| Locking of plug-in connection | locking lever |
| Material group | I |
| Mismating protection | Yes |
| Number of Poles | 12 |
| Number of connection types | 1 |
| Number of levels | 2 |
| Pin spacing | 7.5 mm (0.295 inch) |
| Product Group | 3 (Multi Conn. System) |
| Rated current | 16 A |
| Rated impulse voltage (II / 2) | 6 kV |
| Rated impulse voltage (III / 2) | 6 kV |
| Rated impulse voltage (III / 3) | 6 kV |
| Rated voltage (II / 2) | 1000 V |
| Rated voltage (III / 2) | 630 V |
| Rated voltage (III / 3) | 500 V |
| Solid conductor | 0.2 … 2.5 mm² / 24 … 12 AWG |
| Strip length | 9 … 10 mm / 0.35 … 0.39 Inch |
| Total number of connection points | 24 |
| Total number of potentials | 12 |
| Weight | 35.068 g |
| Width | 104.05 mm / 4.096 inch |
