Datasheet Wago 2002-553 — Ficha de datos
Tira de conector TOPJOB S; para la serie 2002; para ranura de contacto de puente; 3 polos; gris
Precios
Paramétricos
| Color | gray |
| Connection technology | Push-in CAGE CLAMP® |
| Страна происхождения | DE |
| Fine-stranded conductor | 0.25 … 4 mm² / 22 … 12 AWG |
| Fine-stranded conductor with ferrule, push-in termination, from | 0.75 mm² / 18 AWG |
| Fire load | 0.153 MJ |
| Global Trade Item Number (GTIN) | 4045454178345 |
| Insulating material | Polyamide 66 (PA 66) |
| Marking level | Center/side marking |
| Nominal cross section | 2.5 mm² |
| Number of Poles | 3 |
| Product Group | 22 (TOPJOB S) |
| Rated current | 24 A |
| Rated impulse voltage (III / 3) | 6 kV |
| Rated voltage (III / 3) | 500 V |
| Solid conductor | 0.25 … 4 mm² / 22 … 12 AWG |
| Solid conductor, push-in termination | 0.75 … 4 mm² / 18 … 12 AWG |
| Strip length | 10 … 12 mm / 0.39 … 0.47 Inch |
| Total number of connection points | 3 |
| Total number of potentials | 3 |
| Type of wiring | Side-entry wiring |
| Weight | 8.241 g |
| Width | 15.6 mm / 0.614 inch |
Linea modelo
Serie: 2002 (100 desde 422)
- 2002-407/000-005 2002-407/000-006 2002-408 2002-408/000-005 2002-408/000-006 2002-409 2002-409/000-005 2002-409/000-006 2002-410 2002-410/000-005 2002-410/000-006 2002-4101 2002-4111 2002-4127 2002-4131 2002-4141 2002-4157 2002-4191 2002-4192 2002-423 2002-423/000-005 2002-423/000-006 2002-433 2002-434 2002-435 2002-436 2002-437 2002-438 2002-439 2002-440 2002-472 2002-473 2002-473/011-000 2002-474 2002-475 2002-475/011-000 2002-476 2002-477 2002-477/011-000 2002-478 2002-479 2002-479/011-000 2002-480 2002-481 2002-481/011-000 2002-482 2002-492 2002-492/000-012 2002-493 2002-511 2002-541 2002-549 2002-552 2002-553 2002-554 2002-555 2002-556 2002-557 2002-558 2002-559 2002-560 2002-611 2002-6301 2002-6302 2002-6303 2002-6304 2002-6305 2002-6306 2002-6307 2002-6308 2002-6391 2002-6392 2002-6401 2002-6402 2002-6403 2002-6404 2002-6405 2002-6406 2002-6407 2002-641 2002-649 2002-7111 2002-7192 2002-7211 2002-7292 2002-800 2002-800/1000-410 2002-800/1000-411 2002-800/1000-541 2002-800/1000-542 2002-800/1000-836 2002-810 2002-820 2002-880 2002-880/1000-411 2002-880/1000-541 2002-880/1000-542 2002-880/1000-836 2002-991 2002-992
Clasificación del fabricante
- Rail / Chassis Terminal blocks
Otros nombres:
2002553, 2002 553
